In line with the set industry parameters, we are offering a wide array of Hydraulic Cots Grinding Machine, which is equipped with electronic timer and LCD display of seconds for setting grinding time automatically for uniform grinding and consistency in grinding result. These machines are equipped with automatic traverse with the help hydraulic pressure, center less grind attachment having double roller system, automatic timer provided for setting grinding time and highly efficient dust extraction unit provided separately. In order to suit varied demands of our precious customers, this Hydraulic Cots Grinding Machine is available in several specifications.
HYDRAULIC COTS GRINDING MACHINE CGM-01
- Buffing of Top Roller is on abrasion method.
- Surface finish of Cots after grinding gives R.A. value of 0.2 to 0.5 dispensing on the quality of Cots.
- Automatic traverse with the help hydraulic pressure, center less grinding attachment having double roller system.
- Cylindrical Drum Emery having width of 200 mm, desired pressure on arbor while fringing with center-less attachment can be set.
- Self retracting and Roller Bearing Mounted Tail Stock.
- Automatic Timer provided for setting Grinding Time. Accuracy after Grinding Taper - 0.01mm, Eccentricity - 0.01 mm.
- Highly efficient Dust Extraction Unit provided separately all values obtained on this M/c are as per highest International Standards.
- Production : 250 to 400 arbors/hr. for Ring Frame & Speed Frame.
